1u Rack Mount 6 Way IEC C19 PDU with 1p Circuit Breaker

AZE 1U Rack Mount 6 Ways IEC C19 PDU, with  1P Circuit Breaker-PDH1U06C19P1The power distribution unit, also known as a pdu, provides a rack mountable power solution to 19" cabinets and racks. 4 and 8 way versions are to be mounted horizontally, where as the 8, 10, 12 16 and 24 way are to be mounted verticall

Featured Products

AZE 1U Rack Mount 6 Ways IEC C19 PDU, with  1P Circuit Breaker-PDH1U06C19P1

The power distribution unit, also known as a pdu, provides a rack mountable power solution to 19" cabinets and racks. 4 and 8 way versions are to be mounted horizontally, where as the 8, 10, 12 16 and 24 way are to be mounted vertically for use in the bigger floor standing cabinets. Designed to manage power supply within 19-inch server racks, this rackmount PDU (Power Distribution Unit) conveniently provides ample outlets for equipment within a network cabinet. Mounting holes are located on both ends of the unit making it suitable for horizontal mounting on the inside of the server cabinet.

AZE power distribution unit(PDU) are designed for installation and used in networking cabinets and racks, in order to meet the different power need,the features are:

- 19" horizontally or vertically mounting options
- 1U,1.5U,2U Heights
-  Plastic or Aluminum Housing Cases
- Various sockets output, plug input types with different choices of functions modules.

1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker
1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker

1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker
1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker

ModelPDH1U06C19P1
Physical Characteristics
PDU Dimension LxWxH=482.6x44.4x44.4mm (19 inch,1U)
Mounting Length482.6mm/19inch
Housing Case,ColorAluminum Alloy,Black
Plastic Flame Retardant RatingUL94V-0 Grade
Input Parameters
Rated Input Voltage 250V, 50/60Hz
Power Cable3*1.5mm²x2M
Plug StyleIEC60302 C20 10A,250Vac
Max.Input Current10A
Output Parameters
Socket StyleIEC60302 C19 10A,250Vac
Output Socket Quantity6
Rated Output Voltage250Vac
Max. Output Current10A
Max. Output Power3500W
Functional Modules
ControlN/A
Protection1P Circuit Breaker
Testing Items & Certifications
Hi-Pot TestPass
Ground Bond Test Pass
IR Test Pass
CertificationsCE
ApprovalRoHS
What's Included
                            1,PDU x 1pc ; 2,Mounting Hardware
1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker
ModelDescription
PDH1U05C19P11U Rack Mount 5 Ways IEC C19 PDU, with 1P Circuit Breaker
PDH1U06C19DS1U Rack Mount 6 Ways IEC C19 PDU, with Double Breaker Switch
PDH1U06C19OP1U Rack Mount 6 Ways IEC C19 PDU,with Overload Protection
PDH1U06C19P11U Rack Mount 6 Ways IEC C19 PDU, with  1P Circuit Breaker
PDH1U06C19SPD31U Rack Mount 6 Ways IEC C19 PDU,with 3-Lights Surge Protection
PDH1U06CB19OPDS1U Rack Mount 6 Ways IEC C19 Anti-shedding PDU,with Overload Protection and Double Break Switch
1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker
1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker
1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker
1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker


1u Rack Mount 6 Ways IEC C19 PDU with 1p Circuit Breaker
Q1:   Are you a manufacturer?
AZE: Yes, we are a experienced manufacturer- professional customer support team, experienced R & D team and effiency production lines.

Q2:   Do you have any MOQ limit for server rack pdu ?

AZE: Low MOQ, 1pc for sample checking is available.

Q3:  Can I get sample order?
AZE: Yes, we would like to get your sample order for testing our quality, the sample cost is paid by the customer.

Q4:   Are you able to customize products based on requirements?
AZE: Yes, we can provide OEM & ODM services.

Q5:   How long is the product warranty ?
AZE: We guarantee all our products 12 months warranty without artificial damage

Q6:  How do you ship the goods and how long it will take?
AZE: We will use UPS, FedEx, DHL or air freight for sample order, it will arrived within 7-14 days.
For the bulk order with container sea shippment , it takes approx 30-35 days to arrived at the customer side.

Q7:   Can i visit your factory?
AZE:  Welcome to visit us, please talk with your account manager to arrange your schedule.

Q8: What is your payment terms?
AZE: 50% T/T in advance, 50% against B/L copy.
